STW1000
| ST Video-Film Technology Co., Ltd. | ||
| ADD：67th Floor, Seg Plaza, Huaqiang North Rd. Futian Dist.Shenzhen 518000.China Contact: Frank whatsapp:+86 18682242151 E-mail: frank@stvfe.com.cn | ||
| Excellent non-line-of-sight transmission performance | ||
 |
||
| Transmiter | Receiver | |
| Antenna Mode | 1T1R+1R | |
| Transmission delay | 70ms | |
| Operating frequency | 1.4GHz | |
| Transmission power | 33dBm +/- 1dBm | / |
| Interface | Output：Tally, RS232/422；Input:HDMI SDI | Output：HDMI, SDI, SDI Loop； Input: Tally（DB9), RS232/422 |
| resolving power | 720p50/59.94/60 ， 1080p23.98/24/25/29.97/30/50/59.94/60，1080i50/59.94/60 | |
| Power consumption | 12W | |
| Operating voltage | 7~36V | |
| Transmission Distance | 1.2km (20MHz, 15Mbps) | |
| Receiving Sensitivity | / | -94dbm@4Mbps |
| Temperature | 0~40 C(Working);-20~80 C(Storage) | |
| Bandwidth | 5MHz ， 10MHz ，15MHZ ，20MHZ | |
| Audio Format | PCM,MP2 | |
| Working power supply | DC12V / 2A | |
| SDI protocol | HD/3G(A/B) ；SMPTE 296M ；SMPTE274M | |
| Network mode | Peer to peer private protocol, RTSP protocol | |
| Product Size | 155*94*35mm ( MAX:157*102*44 mm） | |
Overview
Base on advanced wireless transmission technology, STW1000 has excellent non-line-of-sight transmission, anti-interference, and ultra-long-distance transmission performance. It extends the application of wireless video transmission to more complex scenarios, such as video transmission between different floors, indoor to outdoor transmission, outdoor blocking scenario, etc.
Features
1. Excellent non-line-of-sight transmission performance
2. Ultra-long distance range up to 1KM (LOS)
3. Ultra-low video transmission latency to 70ms
4. Up to 1080p60Hz resolution
5. Support SDI & HDMI IN, HDMI OUT, dual SDI OUT and SDI LOOP OUT
6. Support audio Line-in and Line-out
7. Support Tally, RS232/422/485 control signals
Interface
Transmitter
Receiver
Application Diagram
Specifications
| Transmitters | Receiver | |
| AntennaMode | 2T2R MIMO External Antenna | |
| OperatingFrequency | 1.4GHz | |
| Video Resolution | 720p50/59.94/60, 1080p23.98/24/25/29.97/30/50/59.94/60, 1080i50/59.94/60 | |
| Video Port | HDMI IN x1, SDI LOOP OUT+SDIIN | HDMI OUT x1, SDI OUT x2 |
| OperatingVoltage | 7~36V | |
| External Audio | Line-in and Line-out | |
| Transmission Distance | 1KM/3280ft | |
| PowerConsumption | ≦12W | |
| Product Size | 155(L)*94(W)*35(H) mm (MAX:157(L)*102(W)*44(H) mm) | |
| Audio Format | PCM, MP2 | |
| Battery Installation | Sony NP-F DV Battery Dock | |
Application Scenarios
Because the core feature of excellent non-line-of-sight transmission, Thunder can be used in many complex scenarios.
